Lesson 5.5. switch..case statement

In C, there is a conditional operator (switch..case) to compare a variable with several expressions.

Syntaxe

The general syntax is:

switch ( Variable ) {
    case Value1:  Instruction block 1;
                  break;

    case Value2:  Instruction block  2;
                  break;
    ...

    case ValueN:  Instruction block  N;
                  break;

    default:      Default instruction block;
}

• If Variable is equal to Value1, then instruction block 1 is executed.
• If Variable is equal to Value2, then instruction block 2 is executed.
• ...
• If Variable is equal to ValueN, then instruction block N is executed.
• If Variable is not equal to any of the valueX, the default block of instructions is executed.

Here is the associated flowchart:

Exemple

Here is an example that repeats a previous exercise. This time the sequence of if is replaced by a single switch..case :

// Display numbers in words
switch (number) {
    case 0: printf ("zero\n"); break;
    case 1: printf ("one\n"); break;
    case 2: printf ("two\n"); break;
    case 3: printf ("three\n"); break;
    case 4: printf ("four\n"); break;
    case 5: printf ("five\n"); break;
    case 6: printf ("six\n"); break;
    case 7: printf ("seven\n"); break;
    case 8: printf ("eight\n"); break;
    case 9: printf ("nine\n"); break;
    default : printf ("%d is not a number between 0 and 9\n", number);
}

Exercise

Exercise 1

Write a program that asks the user to enter a number. Using the switch..case statement display the number spelled out in French. This page list the spelling of French number.

unsigned int number;

// Asks the user to enter a number
printf ("Enter a number between 0 and 9 : ");
scanf ("%u", &number);

// Displays the number in full in French
// COMPLETE HERE

Here is the expected display:

Enter a number between 0 and 9 : 7
sept

Enter a number between 0 and 9 : 12
12 is not a number between 0 and 9.

#include <stdio.h> int main(void) { unsigned int number; // Asks the user to enter a number printf ("Enter a number between 0 and 9 : "); scanf ("%u", &number); // Displays the number in full in French // COMPLETE HERE return 0; }

Exercise 2

The variable number is now of type char and contains a character. If the character represents a number (from 0 to 9), the program displays this number in full in French. If it is not a number, we display : Non valid character.

char number = '7';

// Displays the number in full in French
// COMPLETE HERE

Here is the expected display with char number = '7';

sept

Here is the expected display with char number = 'x';

x is not a character between 0 and 9.

#include <stdio.h> int main(void) { char number = '7'; // Displays the number in full in French // COMPLETE HERE return 0; }

Exercise 3

Write a program that converts a hex character containing a hexadecimal symbol (from 0 to F). The result of the conversion in decimal will be assigned to the variable dec. We process only uppercase characters for the letters from A to F. If the character is not valid, we put -1 in the variable dec.

// Character to convert
char hex = 'B';
// Result in base 10
short dec;

// Convert hex to decimal (base 10)
// COMPLETE HERE

// Display the conversion result
if (dec==-1) printf ("Non valid hexadecimal number\n");
else printf ("0x%c = %d in decimal\n", hex, dec);

Here is the expected display with char hex = 'F';

0xF = 15 in decimal

Here is the expected display with char hex = 'f';

Non valid hexadecimal number

#include <stdio.h> int main(void) { // Character to convert char hex = 'B'; // Result in base 10 short dec; // Convert hex to decimal (base 10) // COMPLETE HERE // Display the conversion result if (dec==-1) printf ("Non valid hexadecimal number\n"); else printf ("0x%c = %d in decimal\n", hex, dec); return 0; }

Quiz

What does the following code display?

int x = 2;
switch (x) {
    case 0: printf ("Bonjour"); break;
    case 1: printf ("Hola"); break;
    case 2: printf ("Konnichiwa"); break;
    default : printf ("Hello");
}

---

What does the following code display?

int x = 3;
switch (x) {
    case 0: printf ("Bonjour"); break;
    case 1: printf ("Hola"); break;
    case 2: printf ("Konnichiwa"); break;
    default : printf ("Hello");
}

---

What syntax is used to test a range with a switch..case?

switch (grade) {
    //...
    ??? : printf ("Higest honors"); break;
    //...
}

---
